2004 Index MS 18C

Index MS 18C Year of construction 2004 / Installation 2008 Showroom machine until 12/2007 / from 1/2008 in production INDEX C200 control with double NCU Slide 1.1 NC controlled X and Z axes Slide 1.2 Fixed X axis, NC controlled Z axis Slide 2.1 Fixed X axis, NC controlled Z axis Slide 2.2 NC-controlled X and Z axes Slide 3.1 NC controlled X and Z axes Slide 3.2 NC-controlled X and Z axes Slide 4.1 NC controlled X and Z axes Slide 4.2 NC controlled X and Z axes Slide 5.1 NC controlled X and Z axes Slide 5.2 NC controlled X and Z axes Slide 6.0 NC controlled X and Z axes Slide 6.2 Rotating X and Y axes with NC controlled Scara transformation and Z axis Finished pieces unloading via slide in pos. 6 Integrated conveyor belt for finished parts - pos. 6 Swarf conveyor with hinged belt, discharge height: 1200 mm Drum filter, flow rate 350 L / min, filtration degree 100 Mikron, tank capacity 600 liters High pressure system 55 l / min at 35 bar - 5.5 KW Heat exchanger for refrigeration system Oil mist extractor SH 2000-PEV-T / TR, two-stage Fire system CN option for synchronous spindle / polygonator Transmit- / Tracyl functions on C200-4D NC-Option Scara-Transformation ARTIS tool breakage control system Electronic bar progress control Position 6.2 synchronized pickup spindle with internal coolant
